What is a diesel concrete mixer pump
The concrete mixer pump combines the concrete mixer and concrete pump together, achieving integration of pump station. It is most suitable for the houses and commercial buildings under 30 floors, small bridges, water conservancy, power and communication for which the sites are scattered and on-site mixing is required.
Main advantages
Hydraulic valves is Beijing Hade(chinese best brand),
Main pump is Kawasaki Brand
Sealing American Parker bran
Hydraulic Hose is Italy Manuali
Electric elements are france Schnider brand,
PLC Japanese OMRON brand,
The mixer drum made by Q345B strengthened plate (6mm thickness), and pipeby high wear-resistant steel.
Technical performance
Hydraulic system
1. Double open hydraulic loops with two pumps, makes the whole hydraulic system and maintenance much simpler.
2. The high-low pressure switch is automatic, thus reducing the trouble of dismantling and installing the oil pipe
3. Hydraulic system has safe relief protection. When the system pressure is over, the main oil pump cutting device makes itself be protected reliably.
Electric control system
1. The wireless remote equipment is convenient for operation far away.
2. It has a simple electric control system with reliable performance and easy maintenance.
Mechanical system
The agitator have unique form, which separates the hydraulic motor from agitator bearing pedestal.At the same time, adopting large displacement motor ensures that the agitator moment is big enough.
Cooling system
The radiator equipment makes the working oil temperature of hydraulic system below 70℃ and makes the machine in normal status.
Tips: Welcome to leave message below to inquire diesel concrete mixer pump price.
Technical Parameters
Items | Units | Parameters | |
Whole performance of machine | Pump Max. theo. concrete output | m3/h | 40 |
Charging (hopper )capacity of mixer | m3 | 0.56 | |
Discharging capacity of mixer | m3 | 0.35 | |
Max.concrete pumping pressure | MPa | 10 | |
Distribution valve type | S Valve | ||
Concrete cylinder diameter stroke | mm | 160×1000 | |
Hopper capacity | L | 400 | |
Outlet diameter | mm | 125 | |
Power system | Diesel engine model | -- | DEUTZ |
Electrical engineering power | kW | 82 | |
Rotate speed | r/min | 2300 | |
Hydraulic system | Circuit type | Open circuit | |
Pumping system pressure | MPa | 31.5 | |
Mixing system pressure | MPa | 6 | |
Capacity of oil tank | L | 350 | |
The biggest transportation is away from vertically (/horizontal) | m | 150/600 | |
Other parameters | Mixer capacity | m3/h | 10-14m3/h |
Max. aggregate diameter | mm | 40 | |
Inside diameter of delivering pipe | mm | Ф125 | |
Dimensions：length×width×height | mm | 6000x2300x3150 | |
Total weight | kg | 5800kg | |
Tire | Pcs | 4 | |
